Image Sensor |
1/3" Progressive Scan CMOS |
|---|---|
|
Effective Pixels |
1280(H)*720(V) |
|
Min. Illumination |
0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
|
Shutter Time |
1/25(1/30) s to 1/50,000 s |
|
Lens |
2.8 - 12 mm @ F1.4 |
|
Angle of view: 80°-27.2° |
|
|
Lens Mount |
φ14 |
|
Angle Adjustment |
Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360° |
|
Day & Night |
ICR |
|
Synchronization |
Internal synchronization |
|
Video Frame Rate |
720p@25fps/720p@30fps |
|
HD Video Output |
1 Turbo HD output |
|
S/N Ratio |
More than 52dB |
|
General |
|
|
Working Temperature/Humidity |
-40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
|
Power Supply |
12V DC |
|
Power Consumption |
Max. 4.5W |
|
Weather Proof Ratings |
IP66 |
|
IR Range |
Up to 40m |
|
Dimension |
92 × 84.8 × 269.6mm(3.62” × 3.34” × 10.6”) |
|
Weight |
1010g (2.23 lb) |
